Micromanipulator (PX55 System)
Model: MicromanipulatorA dual-arm micromanipulation system built around the PX55 research-grade inverted platform, supporting ICSI, embryo biopsy, nuclear transfer and patch-clamp work within a 25 mm ultra-wide field of view.
Specifications
| Structure | Two independent arms, holding pipette left and injection pipette right |
|---|---|
| Platform | PX55 BIO / PX55 FS8 / PX55 FS8 PLUS |
| Drive | Two-stage coarse and fine control; mechanical, hydraulic or motorised |
| Working space | Column tilts through 40°, arms and dish sit in place together |
| Stage | 130 × 90 mm mechanical stage; glass plate and dish holders optional |
| Observation | Brightfield, phase contrast, Hoffman, DIC, fluorescence (per PX55 build) |
| Objectives | Long working distance phase objectives 4×/10×/20×/40×/60×; fluorescence optional |
| Camera ports | Four ports on the stand; Moticam Pro S5 Lite / S7 / S12 Plus |
| Extension | Incubation chamber and CO2 control for long sessions and time-lapse |
| Software | Motic Analysis Bio with coding recognition, Z-stack fusion and multi-dimensional imaging |
Features
- Arms are fixed to the same stand as the microscope, so the field stays put while the pipette moves
- A 72 mm condenser working distance leaves room for both pipette holder and dish in the light path
- Four camera ports on the stand allow simultaneous capture of the injection sequence and fluorescence
- Incubation and CO2 modules hold 37 °C and 5% CO2 throughout the procedure
- Captured images carry magnification and filter-cube metadata, ready for archiving
Applications
- ICSI in reproductive medicine centres
- Embryo biopsy and preimplantation genetic testing
- Nuclear transfer and somatic cell cloning
- Microinjection into stem cells and organoids
- Transgenic and gene-editing microinjection
- Patch clamp and electrophysiology electrode work
